ROLLCLIP A

$50.00

Pulley-carabiner that facilitates installation of the rope when the pulley is connected to the anchor

ROLLCLIP A is a pulley-carabiner with a gate opening on the pulley side that facilitates the installation of the rope when the pulley is fixed to the anchor. It is available with an automatic TRIACT-LOCK locking system, or without a locking system. ROLLCLIP A may be used with a CAPTIV positioning bar to favor loading of the carabiner along the major axis, to limit the risk of it flipping, and to keep it integrated with the device.

Pulley-carabiner that facilitates installation of the rope when the pulley is connected to the anchor

ROLLCLIP A is a pulley-carabiner with a gate opening on the pulley side that facilitates the installation of the rope when the pulley is fixed to the anchor. It is available with an automatic TRIACT-LOCK locking system, or without a locking system. ROLLCLIP A may be used with a CAPTIV positioning bar to favor loading of the carabiner along the major axis, to limit the risk of it flipping, and to keep it integrated with the device.

Detailed description

  • Easier handling:

    - sheave mounted on sealed ball bearings for excellent efficiency

    - gate opening on the pulley side facilitates installation of the rope when the pulley is fixed to the anchor

    - may be used with a CAPTIV positioning bar to favor loading of the carabiner along the major axis and to limit the risk of it

    flipping

    - Keylock system prevents any accidental snagging of the carabiner when putting the pulley in place

  • H cross-section of carabiner:

    - ensures an improved strength-to-weight ratio

    - protects markings from abrasion

  • Available in versions with or without TRIACT-LOCK locking system

Specifications

  • Material(s): aluminum

  • Min. rope diameter: 7mm

  • Max. rope diameter: 13mm

  • Sheave diameter: 18mm

  • Maximum working load: 2 x 2 = 4kN

  • Efficiency: 85%

  • Major axis strength: 20kN

  • Minor axis strength: 8kN

  • Open gate strength: 7kN
